Guide Bar 16″ 3/8″ LP .050″ 56DL Small Bar Mount (A095)
Price range: $48.00 through $75.00
Rec. retail price incl GST
The gentle curve and small nose radius reduce the risk of kickback and facilitate good cutting control. Bars are coated for protection against scratches and corrosion.
| Product data | Guide Bar 10" 3/8" LP .050" 40DL Small Bar Mount (A095) Art no: 501 95 92‑40 | Guide Bar 12" 3/8" LP .050" 45DL Small Bar Mount (A095) Art no: 501 95 92‑45 | Guide Bar 14" 3/8" LP .050" 52DL Small Bar Mount (A095) Art no: 501 95 92‑52 | Guide Bar 16" 3/8" LP .050" 56DL Small Bar Mount (A095) Art no: 501 95 92‑56 | Guide Bar 14" 3/8" LP .050" 52DL Small Bar Mount (T095) Art no: 501 95 96‑52 | Guide Bar 16" 3/8" LP .050" 56DL Small Bar Mount (T095) Art no: 501 95 96‑56 |
|---|---|---|---|---|---|---|
Bar length (inch) | 10 in | 12 in | 14 in | 16 in | 14 in | 16 in |
Bar length | 25 cm | 30 cm | 35 cm | 40 cm | 35 cm | 40 cm |
Pitch | 3/8" mini | 3/8" mini | 3/8" mini | 3/8" mini | 3/8" mini | 3/8" mini |
Gauge | 1.3 mm | 1.3 mm | 1.3 mm | 1.3 mm | 1.3 mm | 1.3 mm |
Bar type | Laminated | Laminated | Laminated | Laminated | Laminated | Laminated |
Nose type | Sprocket nose | Sprocket nose | Sprocket nose | Sprocket nose | Sprocket nose | Sprocket nose |
Bar mount type | HSM | HSM | HSM | HSM | HSM | HSM |
